MOZA R16 V2 Direct Drive Base

MOZA R16 V2 Direct Drive Wheelbase: Power and Precision for Serious Sim Racers

Step up to the realism of direct drive force feedback with the MOZA R16 V2 Direct Drive Wheelbase. Delivering a robust 16Nm of peak torque, this high-performance wheelbase is designed for serious sim racers seeking an incredibly detailed and immersive connection to the virtual race track. Feel the subtle textures of the road surface, the precise loading of the tires under cornering, and impactful feedback from curbs and collisions.

The R16 V2 features significant advancements over its predecessor, incorporating MOZA's latest sim racing technology. Experience ultra-smooth and highly detailed force feedback thanks to the 21-bit magnetic encoder, providing over 2 million points of resolution per rotation. Coupled with the refined NexGen 4.0 Force Feedback algorithm, the R16 V2 accurately translates in-game physics into realistic and dynamic sensations.

Constructed from aviation-grade aluminum alloy, the MOZA R16 V2 boasts a sleek, durable, and rigid body that effectively dissipates heat, ensuring consistent performance even during extended racing sessions. Its supercar-inspired design makes it a stunning centerpiece for any sim racing setup or home cockpit.

Connectivity is greatly enhanced in the V2 version, with multiple ports allowing direct connection of essential MOZA peripherals like pedals, shifters, handbrakes, and dashboards directly to the wheelbase, simplifying your cable management and setup. The MOZA R16 V2 seamlessly integrates with the MOZA ecosystem and is compatible with a wide range of popular PC racing simulator titles. Full customization of force feedback settings and features is available through the intuitive MOZA Pit House software and mobile app.

Key Features:

• Powerful 16Nm Peak Torque: Delivers strong and detailed force feedback for realistic immersion.
• V2 Enhanced 21-Bit Encoder: Provides exceptional precision and smoothness with over 2 million resolution steps.
• NexGen 4.0 Force Feedback Algorithm: Advanced processing for accurate and dynamic force feedback effects.
• Aviation-Grade Aluminum Alloy Body: Durable, rigid construction with effective passive cooling.
• Ultra-Low Static Torque: Ensures a smooth feel without cogging or notchiness.
• Enhanced Connectivity (V2 Improvement): Dedicated ports for direct connection of multiple MOZA peripherals.
• Wireless Wheel Communication: Clean and reliable data transmission with MOZA wheels.
• Intelligent Temperature Control: Maintains consistent performance during long racing sessions.
• MOZA Pit House Software & App: Comprehensive tools for customization, tuning, and updates.
• Wide PC Sim Compatibility: Supported by all major racing simulation titles.
• Versatile Mounting: Supports bottom and side mounting (optional bracket may be required).

Technical Specifications:

• Model: MOZA R16 V2 Direct Drive Wheelbase
• Peak Torque: 16 Nm
• Peak Power: 360W
• Encoder Resolution: 21-bit (2,097,152 steps)
• Housing Material: Aviation-grade Aluminum Alloy
• Design: Supercar-inspired
• Dimensions: 327mm x 170mm x 130mm (L x W x H)
• Weight: Approximately 8.9 kg
• Input Voltage: 110V~220V AC → 36V DC
• USB Refresh Rate: 1000Hz
• Motor Type: High-Performance Slanted Pole Servo Motor with Carbon Fiber Wrapped Rotor
• Connectivity: Wired (USB to PC), Wireless (to MOZA Wheels), Direct Ports for MOZA Peripherals (Pedal, Dash, Shifter, Handbrake, E-stop - Specific port types like RJ11, RJ12, RJ45, USB may vary, refer to manual)
• Quick Release: Supported (MOZA Quick Release)
• Supported Platform: PC (Windows)
• Mounting Method: Bottom Mounting (4-hole pattern), Side Mounting (with optional side/front mount bracket)
• Force Feedback Technology: Direct Drive, NexGen 4.0 FFB Algorithm
• Telemetry: Supported
• App Control: Supported (MOZA Pit House, MOZA App)
• Hands-off Protection: Supported
• Speed-dependent Force Feedback Dampening: Supported
• Force Feedback Equalizer: Supported
• Online Firmware Upgrade: Applicable

Unleash the full potential of your sim racing with the MOZA R16 V2 Direct Drive Wheelbase – combining powerful force feedback, advanced technology, and premium build quality for an unforgettable experience.
